Superior comfort to keep you productive throughout the work day.
Comfortable Working Environment
Spacious and comfortable operator station with excellent visibility and legroom keeps the operator comfortable and reduces fatigue. Standard features include:
- Reclining suspension seat with adjustable wrist rests.
- Pilot operated controls on all services including travel levers and dozer functions.
- Two post canopy design for better visibility to the work area.
- A pattern control changer (not available in all regions) is accessible from the cab to switch between excavator and backhoe style controls.
- Ample storage space under the seat that can be locked for added security.
Optional Enclosed Cab
For even greater operator comfort, an enclosed cab is available as an option and features:
- Sealed cab with heat and optional air conditioning to keep you comfortable in a wide range of conditions.
- Radio ready with speakers and easy radio installation.
- Removable lower front window and sliding windows for excellent overall visibility.
- Gas assisted front window slides up with minimal effort.
- Sliding door system offers good access and maintains the machine’s compact dimensions, reducing the risk of damage.
Joystick ControlsThe boom swing and auxiliary hydraulic functions are located at your fingertips providing smooth, easy operation. These joystick mounted controls deliver more productivity through precise movement of the boom swing and auxiliary functions. They also eliminate foot pedals and free up the floor for more room for the operator’s feet. 100% pilot controls provide consistent flow and pressure throughout the life of the machine. This also allows all controls to be locked out while starting the machine and when the safety lockout bar is in the up position.
Powerful digging with precise control.
StabilityAll four D-Series models feature increased stability over the previous series, while maintaining the compact radius design. This increased stability leads to more productivity and versatility through the use of heavier work tools and the optional long stick.
Fast, Powerful Digging with Load Sensing HydraulicsHigh digging forces and fast cycle times deliver the productivity that your job demands. Load sensing hydraulics optimize flow for smooth, powerful performance and increased fuel efficiency.
EngineHigh performance power train provides optimized engine horsepower and strong performance. Engine meets U.S. EPA Tier 4 Interim and EU Stage IIIA emissions requirements. Automatic engine idle automatically lowers engine revolutions when not in use to conserve fuel and lower environmental noise and emissions. The D-Series models feature an engine kill switch conveniently located in the cab and accessible from ground level.
Automatic Two SpeedWith the standard automatic two speed feature, the machine will automatically balance high speed and torque travel requirements based on the conditions to give the operator the optimum speed and control. The machine can be put in low gear if slower travel is desired while in tight conditions.
200 Degree Bucket RotationIndustry leading bucket rotation of over 200 degrees provides greater material retention during truck loading. It also allows for easier vertical wall digging without having to reposition the machine.
Zero Tail Swing
Work in the tightest areas.
Zero Tail SwingNew to the D-Series, the 303.5D CR and the 304D CR models feature a zero tail swing design. On these models, the radius of the upper body stays entirely within the width of the undercarriage.
Coupler and Work Tool Options
New coupler design and multiple work tools increase versatility.
CouplersThe D-Series couplers have a new design with a choice of either a mechanical pin-grabber or the new hydraulic pin-grabber quick coupler option. The new design uses a wedge to keep the tool secure to the coupler, reducing wear and maintaining a tight fit through the life of the coupler. The new hydraulic coupler option allows the operator to change tools without leaving the comfort of the cab. Hydraulic quick coupler lines are available from the factory as an option.
Wide Range of Work Tools
A wide range of Cat Work Tools have been designed specifically for the Cat Mini Hydraulic Excavators to maximize machine performance. Available work tools include:
- Buckets (heavy duty and heavy duty capacity)
- Tilting, Ditch Cleaning Buckets
- Hydraulic Hammers
- Thumbs (not available in all regions)
- Vibratory Compactors
- Shears (boom mounted on 305D CR/305.5D CR only)
- Quick Coupler
Standard Thumb Ready Sticks (optional in Europe)Machines come standard with stick mounted brackets, ready to fit a hydraulic thumb for even greater machine versatility. A factory installed bracket and relief valve make hydraulic thumb installation simple and cost-effective.
Standard Auxiliary Lines and AccumulatorOne-way and two-way auxiliary lines (combined function), including quick connections, are fitted as standard equipment so the machine comes ready to work. A standard accumulator allows for auxiliary pressure to be released, making connecting and disconnecting work tools safer and easier.
Standard dozer blade maximizes productivity.
Simple Dozer Control with Float FunctionThe dozer function is pilot controlled from inside the cab, providing smooth, proportional operation. The standard float function is enabled by pushing the lever fully forward into the detent position. Cleanup and backfilling is easier since the operator does not have to adjust the blade height during travel.
Excellent Blade VisibilityVisibility to the blade is excellent in any position, allowing the blade to be positioned behind the operator and away from the front linkage for better access when back dragging and finishing in tight areas.
Angle Blade OptionIncrease machine versatility with the Cat angle dozer blade. Built for strength and durability, the hydraulic angle blade features a hardened steel wear edge and good protection to cylinders and hydraulic lines. The angle blade can be positioned straight ahead or angled up to 25 degrees to the left or right. This reduces the number of times required to back up and reposition when backfilling so you can finish the job faster. All functions of the blade are controlled with one joystick using a proportional roller switch for the angle function.
Stability and durability.
Rubber TrackThe standard rubber track lets you work on multiple surfaces such as grass, pavement or stone without damaging the surface or machine.
Simplified service and maintenance save you time and money.
Convenient service features make maintenance easy, reducing your downtime:
- Lifting side hood allows access to air filter, main implement valve, 1-way/2-way auxiliary flow selector, accumulator, fuel filter and hydraulic tank. This eliminates the need to lift the cab when maintaining and servicing the machine.
- Swing out rear door provides access to major components and service points including engine oil check and fill, vertically mounted engine oil filter, starter motor and alternator.
- Easy access to the radiator and oil cooler results in simplified cleaning and reduced maintenance times.
- SOSSM oil sampling valve allows easy sampling of the hydraulic fluid for preventative maintenance.
- 500 hour engine oil and filter change period reduces operating costs and machine downtime.
Support you can count on.
Superior Dealer Services
Your Cat dealer is ready to assist you with your purchase decision and everything after.
- Financing packages are flexible to meet your needs.
- Unmatched parts availability keeps you working.
- Make comparisons of machines, with estimates of component life, preventative maintenance and cost of production.
- Your Cat dealer can evaluate the cost to repair, rebuild and replace your machine.
